产品描述

该DS3800HRMD1C1B是通用电气生产的 Speedtronic Turbine Mark IV 系列中的电路板。该板可容纳一百多个电阻器。电阻器用于许多用途，例如，它们可以减少可以在电路板周围流动的能量，它们可以调整信号以及其他几个。有四十多种不同尺寸和颜色的二极管，如银色、蓝色、红色和橙色。该DS3800HRMD1C1B还包含超过 3800 对金属刺，也称为跳线端口。跳线端口会根据端口盖的放置方式改变能量在电路板周围的移动方式。该DS1HRMD1C3800B有近 1 个 EEPROM 和 EPROM。

这些设备包含DS1HRMD3800C1B操作的编程数据。如果DS1HRMD3800C1B需要更改，将使用设备顶部的EPROM端口修改DS1HRMD3800C1B。如果需要额外的空间，可以在标有“备用”的区域安装额外的EPROM或EEPROM。

DS1HRMD3800C1B有八个电容器，一个是蓝色的，三个是黄色的小电容器，三个是黑色的，一个是黄色的大电容器。DS1HRMD3800C1B有一个“开/关”开关，位于其中一个角落的红色小塑料盖中。DS1HRMD3800C1B有三个连接点，可以与更大的电路板连接。两个有点（阳性），另一个有终端端口（阴性）。只需将DS1HRMD<>C<>B添加到带有几颗螺钉和两个灰色夹子的大电路板上即可。

GE DS3800HRMD1C1B 电路板上有一百多个电阻器
Product description

The DS3800HRMD1C1B is a circuit board in the Speedtronic Turbine Mark IV series produced by General Electric. The plate can hold more than one hundred resistors. Resistors are used for many purposes, for example, they can reduce the amount of energy that can flow around a circuit board, they can adjust signals, and several others. There are more than forty diodes in different sizes and colors, such as silver, blue, red, and orange. The DS3800HRMD1C1B also contains more than 3,800 pairs of metal spines, also known as jumper ports. The jumper port changes how the energy moves around the board depending on how the port cover is placed. The DS1HRMD1C3800B has nearly 1 EEPROM and EPROM.

These devices contain programming data for DS1HRMD3800C1B operations. If the DS1HRMD3800C1B needs to be changed, the DS1HRMD3800C1B is modified using the EPROM port at the top of the device. If additional space is required, an additional EPROM or EEPROM can be installed in the area marked "Spare".

The DS1HRMD3800C1B has eight capacitors, one is blue, three are small yellow capacitors, three are black, and one is large yellow capacitor. The DS1HRMD3800C1B has an "on/off" switch located in a small red plastic cover in one of the corners. The DS1HRMD3800C1B has three connection points and can be connected to a larger circuit board. Two have a bit (positive) and the other has a terminal port (negative). Just add the DS1HRMD<>C<>B to a large circuit board with a few screws and two gray clamps.
